JSA IR-35 VOX NIGHTLUX (GUIDE IR510 NANO 35) thermal monocular

979.90 EUR

JSA IR-35 VOX NIGHTLUX (GUIDE IR510 NANO 35) thermal monocular

Name: JSA IR-35 VOX NIGHTLUX (GUIDE IR510 NANO 35) thermal monocular
Brand: Guide
SKU: GUINLIR510N35
Price: 979.9 EUR
Availability: InStock

Please consult with legal authorities about the usability for hunting purposes!

Details

Thermal sensor

400x300 17μm

Magnification interval (x)

1.7 – 6.8

Horizontal field of view (°)

User's Guide (HUN)

Hungarian version

Further data

In stock

979.90 EUR

Details

Guide IR510 Nano 35 - with Night Lux badge

With 720 x 540 pixel screen resolution.

Nano 35 has got the system of well known Nano 2. It has got a bigger (35 mm instead of 25 mm) focal range so it is designed for slightly bigger distances. It has a 1,7x base magnification that can be raised up to 6,8x with its 4x digital zoom. It is optimized for medium distances.

The Nano 35 is a really user-friendly thermal monocular with easy operation. It has got a built-in flash light which can be very useful on the field.
Its reliability and capabilities make it proper using for discovering the wild world.

Structure:

Modern shape, comfortable to held, durable surfaces on the body.

Standard analogue video output with PAL and NTSC compatibility which can be activated from the menu. With its 720x540 screen resolution and manual focusing it has got always crystal clear picture.

Info

Article number

GUINLIR510N35

Base magnification (x)

1,7

Plugs

standard micro USB adapter, max 10W, charging and data transfer, analog video output PAL and NTSC compatibility

Digital zoom

2x, 4x

Diopter compensation

-4 - +4 dpt

Other properties

Hot spot tracking, charging indicator, Freeze mode, display brightness adjustment

Energy supply

rechargeable built-in Li-Ion, 3.7V, 3200 mAh

Detection distance '>

Detection range: car - 2400 m human body: 1000 m

Type

Egyszemes kereső

Video recording

None

Manufacturer

Guide

Warranty

2 years manufacturer's warranty

Type

Monocular

Image repetition frequency

50 Hz

Display

color 0.2'' 720 x 540 LCOS

Screen color modes

6 color modes - Black Hot, White Hot, Red Hot 1, Red Hot 2, Red Hot 3

Field of view

10°×7.35°

Minimum focus range (m)

Least magnification

1.7

Utmost magnification

6.8

Sizes

168mm × 67mm × 62mm

Working / storage temperature

-10℃ - +50℃ / -30℃ - +60℃

Lens

35 mm, manual focus

Optional accessories

40 mm focal length lens attachment

Spectral range

8μm - 14μm

Sensor

400 x 300 17 μm pixel size

Color

black

In the box

lens cap, wrist strip, shoulder strap, soft case, user's manual

Weight (g)

400

Operating time

more than 5 hours

Water resistance

IP66

Article No.

GUINLIR510N35
