Seek Thermal Compact XR thermal camera module for Android USB-C

Article No.:
SEECTAAA
Thermal sensor, The smaller the value the more detail the picture has.: 206x156 12µm Thermal sensor:
206x156 12µm
Magnification interval (x):
1 – 1
User's Guide (HUN), A linkre kattintva letölthető a magyar nyelvű használati útmutató.:

Hungarian version

 User's Guide (HUN):

Hungarian version

Thermal sensor:
206x156 12µm
Seek Thermal Compact XR thermal camera module for Android USB-C
337.56 EUR
Details
Coming soon…
Info
Article number: SEECTAAA Article number:
SEECTAAA
When do I get it?: Orderable When do I get it?:
Orderable
Base magnification (x): 1 Base magnification (x):
1
Plugs: USB-C Plugs:
USB-C
Other properties: Direct measuring range: -40 - +330 °C Other properties:
Direct measuring range: -40 - +330 °C
Detection distance (Information data, that shows the distance an object can be seen from as one pixel. It's just one pixel without shape and contours. The distance, from that the object, game or human body can be identificate with it's shape, is usually much shorter.): <= 550 m Detection distance:
<= 550 m
Type: Telefon modul Type:
Telefon modul
Manufacturer: SeekThermal Manufacturer:
SeekThermal
Warranty: 2 years manufacturer's warranty Warranty:
2 years manufacturer's warranty
Type: Phone module Type:
Phone module
Image repetition frequency: 9Hz Image repetition frequency:
9Hz
Screen color modes: Sensitivity: Can be adjusted Screen color modes:
Sensitivity: Can be adjusted
Least magnification: 1 Least magnification:
1
Utmost magnification: 1 Utmost magnification:
1
Sizes: 25,4x44,4x2,54mm Sizes:
25,4x44,4x2,54mm
Magnification: 1x Magnification:
1x
Old article number: SEECT-AAA Old article number:
SEECT-AAA
Spectral range: 7,5-14µm Spectral range:
7,5-14µm
Sensor: "uncooled microbolometer Vanadium-Oxide (Vox)"206x156 pixel size: 12µm Sensor:
"uncooled microbolometer Vanadium-Oxide (Vox)"206x156 pixel size: 12µm
Color: black Color:
black
In the box: thermal camera, waterproof case In the box:
thermal camera, waterproof case
Weight (g): 14 Weight (g):
14
Product type: Thermal camera, Nightvision Product type:
Thermal camera, Nightvision
Type: Phone module Type:
Phone module
