InfiRay IRS-AC822W-H body wall-built temperature measuring station

Article No.:
IRAIRSAC822WH
Thermal sensor, The smaller the value the more detail the picture has.: 256x192 17μm Thermal sensor:
256x192 17μm
Magnification interval (x):
1 – 1
Horizontal field of view (°), One of the most important value when choosing the proper thermal camera. Bigger values are better for short distance. Less values are better for great distances.: 65 Horizontal field of view (°):
65
User's Guide (HUN), A linkre kattintva letölthető a magyar nyelvű használati útmutató.:

Hungarian version

 User's Guide (HUN):

Hungarian version

Thermal sensor:
256x192 17μm
InfiRay IRS-AC822W-H body wall-built temperature measuring station
InfiRay IRS-AC822W-H body wall-built temperature measuring station
InfiRay IRS-AC822W-H body wall-built temperature measuring station
1
3
Available for order
847.01 EUR
Details
Coming soon…
Info
Article number: IRAIRSAC822WH Article number:
IRAIRSAC822WH
When do I get it?: Orderable When do I get it?:
Orderable
Base magnification (x): 1 Base magnification (x):
1
Tripod thread: bracket for tube stand mount Tripod thread:
bracket for tube stand mount
Plugs: 2*alarm input, 1*alarm output, 1*RS485, DC 12V, 1*RJ45 10M/100M, 1* Bluetooth, 1*USB 2.0, 1 Wiegand Plugs:
2*alarm input, 1*alarm output, 1*RS485, DC 12V, 1*RJ45 10M/100M, 1* Bluetooth, 1*USB 2.0, 1 Wiegand
Other properties:

2 cameras:

thermal + 2 MP CMOS WDR dual camera
AI face recognition and folowing, >30 people/frame
Energy consumption: < 20 W

 Other properties:

2 cameras:

thermal + 2 MP CMOS WDR dual camera
AI face recognition and folowing, >30 people/frame
Energy consumption: < 20 W

Energy supply: 12 V DC Energy supply:
12 V DC
Detection distance (Information data, that shows the distance an object can be seen from as one pixel. It's just one pixel without shape and contours. The distance, from that the object, game or human body can be identificate with it's shape, is usually much shorter.): 0,3 - 1,5 m Detection distance:
0,3 - 1,5 m
Manufacturer: InfiRay Manufacturer:
InfiRay
Warranty: 3 years manufacturer's warranty Warranty:
3 years manufacturer's warranty
Manufacturer's article number: IRSAC822WH Manufacturer's article number:
IRSAC822WH
Alternative power source: 12 V DC Alternative power source:
12 V DC
Image repetition frequency: 50 Hz Image repetition frequency:
50 Hz
Display: 8'', 1280x800 pixel Display:
8'', 1280x800 pixel
Field of view (°): 65°x 40° Field of view (°):
65°x 40°
Least magnification: 1 Least magnification:
1
Utmost magnification: 1 Utmost magnification:
1
Sizes: 126 x 264 x 18,5 mm Sizes:
126 x 264 x 18,5 mm
Measurement properties: Precise temperature measurement: +20 - +35°C at outside temperature.
For indoor use, in an environment free of wind and drafts.
Measuring distance: 0.3 - 1.5 m. Measurement properties:
Precise temperature measurement: +20 - +35°C at outside temperature.
For indoor use, in an environment free of wind and drafts.
Measuring distance: 0.3 - 1.5 m.
Working / storage temperature: +20 - +35°C / -40 - +60°C Working / storage temperature:
+20 - +35°C / -40 - +60°C
Magnification: 1x Magnification:
1x
Lens: 2 MP CMOS dual kamera Lens:
2 MP CMOS dual kamera
Old article number: IRAIRSAC822WH Old article number:
IRAIRSAC822WH
Spectral range: 8 - 14 µm Spectral range:
8 - 14 µm
Sensor: 256 x 192 pixel, VOx uncooled FPA Sensor:
256 x 192 pixel, VOx uncooled FPA
Color: silver Color:
silver
In the box: thermal camera, wall console, cables In the box:
thermal camera, wall console, cables
Product type: Thermal camera, Nightvision Product type:
Thermal camera, Nightvision
