Please consult with legal authorities about the usability for hunting purposes!

Thermal sensor
384x288 12µm
Thermal sensor NETD
40 mK
User's Guide (HUN)

.

Thermal sensor
384x288 12µm
Available for order
2 917.42 EUR
We recommend the following product(s) as accessories
Details

In Hungary and some EU countries, the use of night vision and thermal camera products for hunting purposes is limited, and the use of devices with crosshairs and/or aiming devices is prohibited. Please find out about the regulations in force in your country and follow their changes.

InfiRay presents its new product called Fast Fusion, which will be most appreciated by those hunters who use a mixture of red-dot during daytime hunting and a thermal camera or night vision during their short-range night shots.

The completely universal device can be used day and night by hunters and law enforcement officers, as both the red-dot and the thermal camera, as well as their various fusion and overlapping images, show the scenes perfectly. This technology has already proven itself in industrial thermal cameras for documentation and detailing, now the time has come to convince new users.

You can switch between image modes in seconds, such as Red-Dot, Thermal camera mode, Target highlight mode, when you only project the thermal image onto the game, the environment is the image of the Red-Dot, or Contoured, when the Red-Dot image only shows the warmer body temperature draw a contour around the game. This way you will definitely find the most expressive setting.

Features:

  • Extra large window (34 x 25 mm), 1x magnification
  • High brightness green OLED display
  • Multiple lens coating
  • Ultra precise, extremely reliable

The thermal sensor is a 384x288 pixel resolution unit manufactured by InfiRay, which is used almost as a reference, and which serves with high efficiency in hundreds of thousands of thermal cameras.

The Red-Dot's lens is protected by a precise multiple coating, which also greatly improves the optical properties.

The precision is characterized by the fact that the device comes with a special recoil-damping assembly, which guarantees 1200G shot resistance, so it can be used permanently even with 7.62.

Info
Data storage
32 Gb
Eye relief
90 mm
Plugs
USB-C (5V)
Digital zoom
1x, 2x
Energy supply
2×CR123
Detection distance '>
1818 m
Manufacturer
InfiRay
Warranty
3-year general warranty for the device, 10 years for the sensor, 2 years for the battery
Image repetition frequency
50 Hz
Display
800x600 OLED
Field of view (°)
13.8°×10.4°
Minimum focus range (m)
5 m
Least magnification
1
Utmost magnification
2
Shock resistance
1200 G
Sizes
175×62×86 mm
Working / storage temperature
-40℃-+50℃ / N/A
Lens
19mm f/1.0
Reticle
4.2 MOA
Sensor
384x288 resolution; pixel size: 12 μm; refresh rate: 50Hz; NETD ≤ 40 mK
Color
black
In the box

Fast Fusion red-dot thermal camera, portable quality case, recoil-absorbing assembly, USB-C cable, screws, cleaning cloth

Weight (g)
660g
Operating time

Thermal mode: 4 hours
Red Dot mode: 65 hours

Water resistance
IP67
Product type
Thermal camera, Nightvision
EAN code
6973202303559
Article No.
IRAFAL19
