Guide TK421 Gen2 Kitalpha thermal monocular, Showroom piece

1 493.43 EUR

1 411.96 EUR

Guide TK421 Gen2 Kitalpha thermal monocular, Showroom piece

Name: Guide TK421 Gen2 Kitalpha thermal monocular, Showroom piece
Brand: Guide
SKU: GUITK421V
Price: 1411.96 EUR
Availability: InStock

Showroom piece!
Please consult with legal authorities about the usability for hunting purposes!

Details

Thermal sensor

400x300 17μm

Magnification interval (x)

2.3 – 9.2

Horizontal field of view (°)

11.1

User's Guide (HUN)

Kattintson

Further data

In stock

1 493.43 EUR

1 411.96 EUR

Discount: 5

Saving 81.47 EUR

Details

Equipped with Guide’s new self-developed infrared detector and the patented image processing technology, the TK Gen2 Kitalpha Series captures sharp imaging and is packed with powerful features like image and video recording, smooth zoom, pseudo-color adjustment, approximate ranging and PIP. Personalized image observation is supported in different scene modes. The built-in laser indicator and illuminator facilitate itself to be operated in harsh environment.

Find the HD resolution images

Featuring the new self-developed infrared metal detector, TK Kitalpha Series comes with 400x300 and 640x480 thermal resolution. The 3DNR and PureIR adaptive filtering algorithm provides superior image quality and detailed vision in complex environments.

Outdoor lighting

Enable the outdoor lighting function to generate the visible light images.

Laser indicating

Enable the laser indicating function to locate the object at 200m.

Deliver a stunning HD view

Thanks to the full-color 0.4-inch HD display with 1280 x 960 pixels, the image is crisper and more delicate. It feels like watching 22-inch screen at 1 meter, which greatly improves the observation comfort.

Anti-Fog Eyepiece brings the clarity

This adaptive LCOS eyepiece prevents condensation or fogging and helps you maintain a clear view of your subject.

Bring extended 8x zoom capability

8X zoom can be used to observe targets from long distances for fast location.

One-click switch between three scene modes. Switch between modes to give prominence to objects.

PIP mode for highlighting the target

The PIP mode allows you to zoom in on the target and highlight the details of the target when you are in the complex outdoor scenes.

Multiple color palettes to highlight the target

Six color palettes: White Hot, Black Hot, Iron Red, Blue Hot, Green Hot and Adjustable Red Hot.

Support one-button switch to identify the location of the target instantly, helping to achieve all-weather observations.

IP66, rugged and durable and quality guaranteed

With the IP66 protection level and 1-meter drop test, it is suitable for all kinds of harsh weather. The UN38.3 battery certification, RoHS, CE and FCC certification give the quality assurance.

New App with a variety of functions

The TargetIR APP provides a variety of functions, such as live image and video transmission, for operating the TK Kitalpha Series.

Info

Data storage

16 GB built-in memory

Base magnification (x)

1.7

Tripod thread

1/4 coll

Plugs

micro HDMI output, USB Type C

Digital zoom

1x, 4x

Diopter compensation

-4; +2

Other properties

built-in WiFi, livestream function, USB-C picture transfer to computer, micro-HDMI - HDMI cable (the picture of the monocular can be seen on an externel big monitor)

Energy supply

built-in 2x18650 battery, 6000 mAh

Detection distance '>

Detection: car - 2400 m, human body - 1000 m

Type

Egyszemes kereső

Manufacturer

Guide

Warranty

30 months manufacturer's warranty for the device

Type

Monocular

Image repetition frequency

50 Hz

Display

1280x960 pixel, 0.4'' color LCOS

Field of view

15.4°×11.6°

Minimum focus range (m)

Least magnification

2.3

Utmost magnification

9,2

Sizes

192x65x71 mm

Working / storage temperature

-10 - +50°C / -30°- +60°C

Lens

25 mm F1.1, manual focus

Spectral range

8 - 14 µm

Sensor

400x300 pixel 17 µm pixel méret

Color

black

In the box

thermal monocular, charger, wrist strap, USB-A - USB-C cable, Micro HDMI cable, soft case, warranty card, user's manual

Supported photo resolutions

400x300

Supported video resolutions

400x300

Weight (g)

485

Shock resistance

1 m magasról történő leejtésig

Operating time

akár 5 óra

Water resistance

IP66

Article No.

GUITK421V
